The High-Performance Liquid Chromatography (HPLC) System is a modular, high-precision analytical instrument designed for accurate qualitative and quantitative analysis. This configuration integrates dual high-pressure pumps, sensitive UV detection, precise temperature control, and reliable manual sample injection to ensure excellent separation efficiency and reproducibility.
The system is widely used in pharmaceutical quality control, biotechnology, chemical analysis, food testing, and academic research laboratories. Its modular design allows easy maintenance, upgrades, and customization according to analytical requirements.
Technical Specifications
| Parameter | Specification |
| System Type | Modular HPLC System |
| Pump Model | LC-10ATVP |
| Pump Quantity | 02 Units |
| Flow Rate Range | 0.001 – 10.0 mL/min |
| Maximum Pressure | Up to 40 MPa |
| Detector Model | SPD-10AVP UV-Vis Detector |
| Wavelength Range | 190 – 700 nm |
| System Controller | SCL-10AVP |
| Column Oven | CTO-10AVP |
| Temperature Range | Ambient to 85°C |
| Injector Type | 7725i Manual Injection Valve |
| Injection Volume | 20 µL (Standard Loop) |
| Operation Mode | Manual / Computer Controlled |
| Compliance | GLP / GMP Compatible |
| Power Supply | 220V, 50Hz |
| Customization | Available Upon Request |
Applications
- Pharmaceutical Quality Control
- Biotechnology & Life Sciences
- Chemical Analysis & Research
- Food & Beverage Testing
- Environmental Analysis
- Academic & Contract Research Laboratories
Key Features
- Dual high-pressure pumps for accurate solvent delivery
- High-sensitivity UV-Visible detection
- Stable and programmable column temperature control
- Reliable 7725i imported manual injection valve
- Excellent repeatability and reproducibility
- Modular design for easy maintenance and upgrades
- User-friendly system control and data handling
